Technical parameters of 5200-600 paper machine

Product varieties: high-strength corrugated paper

Fixed quantity: 90 ~ 150 g/m2 (assessed quantitative 105g/m2)

Quantitative calculation: 105 g/m2

Net paper width: 5200mm

Roll width: 5260mm

Net width: 5800 m/min

Working speed: 550m/min

Design speed: 600m/min (50HZ)

Dynamic balance speed: 700m/min

Paper roll dynamic balance speed: 1500m/min

Production capacity: 350t/d (calculated in 90g/m2, 550m/min and 24h)

Rail distance: 6600 mm

Installed capacity: 2386KW (subject to final design)

Transmission mode: all digital ac frequency conversion division transmission
