Main parameters of paper machine:

Product varieties: high-strength corrugated, box board wall paper.

Fixed quantity: 90 ~ 180 g/m2

Production capacity: 500t/d (assessment quantitative 125g/m2, 530m/min)

Net paper width: 5600mm

Roll width: 5660mm

Net width: 6200 mm

Working speed: 550m/min (50HZ)

Design speed: 600m/min

Crawling speed 25m/min

The structural speed is 750m/min

Dynamic balancing speed: 750m/min

Center distance: 7100mm (specific for each part according to design)

Roller balancing: G2.5

Cylinder type dynamic balance: G2.5

Paper roll dynamic balance speed: 2200m/min

Transmission mode: all digital ac frequency conversion division transmission
